With the needs of social development, fiber laser cutting machine is more and more widely used in all walks of life. The edge of optical fiber cutting is smooth and neat, which is suitable for high-precision processing. Fiber laser machine has low gas consumption and high photoelectric conversion rate. It is an energy-saving and environmental protection machine.
Advantages of fiber laser cutter
1. High cutting accuracy. The positioning accuracy of the fiber laser cutting machine is ± 0.02mm.
2. Good cutting quality. The cutting surface is smooth without burrs. Non-contact cutting, the work-piece is less affected by heat when cutting, almost no deformation, no need for secondary processing.
3. Save resources. Fiber laser machine using computer numerical control typesetting, can cut different shapes of products, maximize the utilization of materials, avoid material waste.
4. Safety and environmental protection. Fiber cutting machine processing produces less waste, low noise, no pollution, can effectively protect the health of workers.
5. A wide range of processing. Fiber laser cutting machine can cut a variety of metal materials. For example, stainless steel, carbon steel, aluminum, gold, silver, copper and so on.
Main parts
Body structure
The bed is annealed to eliminate residual stress, stabilize size, and reduce deformation and crack tendency. The whole body spray treatment, with good wear resistance, corrosion resistance performance, strong adhesion, not easy to fall off.
Laser Source
The quality of the Raycus laser is very reliable. The company fully controls production, commissioning, testing, delivery and other manufacturing links in accordance with the standard product management system in the production and testing process.
Laser head
Shanghai Raytool BM110
Raytools laser head is equipped with automatic focusing function, without manual focusing, focusing effect is better. Raytools laser head is equipped with a protective mirror, specially protecting the focusing mirror, which can effectively extend the use time of the focusing mirror.
Control system
The user feedback on the CYPCUT system is very good. The CYPCUT system has a very high efficiency and a very low error rate during use. CYPCUT system has good stability, simple operation, fast running speed, and is a very good control system.
Reducer
Japan Shimpo reducer
The reducer can transform the high-speed rotation of the motor into a low-speed rotation, preventing the mechanical performance from keeping up with the running speed and making the machine work more smoothly. The reducer can reduce the no-load of the motor, thus stabilizing the operating performance of the machine. The reducer can reduce the speed of the motor, thus reducing noise.
Water chiller
In order to meet the needs of laser high temperature control accuracy, the S&A water chiller is constantly upgraded, and the temperature control accuracy is developed from ±1 ° C to ±0.1 ° C. The precision temperature control precision reduces the fluctuation of water temperature and provides stable cooling effect for laser equipment.
Motor and driver
Taiwan Delta servo motor has the characteristics of stable operation, good control ability, fast response, high sensitivity, strict non-linearity index of mechanical characteristics and adjusting characteristics. The work is more reliable, low maintenance and maintenance requirements.
Transmission
Rack and pinion of Taiwan YYC
YYC rack is suitable for heavy load, high precision, high rigidity, high speed machinery, is meeting the needs of fiber laser cutting machine. The effective meshing of unique innovation always ensures that more than two gear teeth contact each other, the effective meshing of unique innovation always ensures that more than two gear teeth contact each other.
Rail guide
Taiwan HIWIN square rail guide
Taiwan HIWIN guide rail has the characteristics of high positioning accuracy, less wear, strong bearing capacity, simple structure and so on. The HIWIN guide rail is rolling friction during movement, which can minimize friction and maintain positioning accuracy.
Application of fiber laser cutting machine
● Application material
Stainless steel, alloy steel, silicon steel, aluminum, aluminum alloy, galvanized plate, aluminum plated zinc plate, copper, silver, gold and other metal materials.
● Application industry
1. Automobile manufacturing industry. Many links in the automotive manufacturing industry can be solved with laser cutting machines. Car doors, body, bottom plate, hood, back cover, airbags, etc., and some small parts can be processed by laser cutting machine.
2.Hardware products industry. There are many hardware products, daily bathroom hardware, hotel daily hardware, hardware decorations, hardware crafts, etc., can be processed by laser cutting machine.
3. Kitchenware industry. There are many kinds of kitchenware, fiber laser cutting machine can meet a variety of customized production, whether it is mass production or small batch personalized production, as long as there are drawings can be produced.
4. The lighting industry. Now the lighting is varied, creating a different home environment. For the cutting of personalized lighting materials, laser cutting machine is very good, all kinds of carving, hollowing can be handy.
| Model | UN-3015A |
| Work Area | 3000*1500 mm |
| Fiber Laser Source | Raycus |
| Laser Power | 3000W |
| Max Moving Speed | 120 m/min |
| Max Acceleration | 1.5G |
| Positional Accuracy | ± 0.02 mm |
| Control System | CYPCUT |
| Motor and Driver | Taiwan Delta servo motor and drivers |
| Reducer | Japan SHIMPO reducer |
| Transmission | Rack and pinion |
| Pneumatic Accessories | Japan SMC |
| Table | Blade table |
| Supported Graphic Formats | NC PLT, DXF, BMP, AI, DST, DWG, etc |
| Work Voltage | 3 phase 380V/50HZ |
| Warranty | 2 years |
| Water Chiller | S&A CW5000 |
Samples of laser cutter
Why choose us？
1. Our company engaged in laser engraving machine industry for many years, has a wealth of product manufacturing experience.
2. We have our own factory, which can realize product customization.
3. We are an industry and trade integrated company, no middlemen to earn the difference, the machine cost-effective
4. We have a professional after-sales team to solve various problems for you.
5. Our products are guaranteed for two years. The whole machine is maintained free of charge for life.
Customer visiting
Many customers come to China to see our factories and speak highly of our products. We have also established a good cooperative relationship with them. We welcome friends from all over the world to visit and guide, we have confidence in our products, you must be worth the trip.
Certificate
We have ISO9001 certification, FDA certification,CE certificate, CCPIT certificate, Saber certificate and other certificates that can be exported to countries around the world. Every step of our production is strictly controlled. The quality of our products is guaranteed and our products are trustworthy.
Q1: What's your date of delivery?
A2: For standard machine, about 15 working days; For customized machine, about 20 working day.
Q2: Do you have CE document and other documents for customs clearance
A2: Yes, we have CE, Provide you with a one-stop service. At first we will show you and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
A3 :How to install and run the machine?
Q3: Our technician have adjusted the machine well before shipping., we will send detail training and operating video, user's manual along with the machine.
95% customers can learn by themselves.
Q4: How to solve it if there is some problem or parts broken during operating metal tube laser cutting machine
A4: If machine technical problem, we have engineer online support service, through remote control, video show, to help solve problem, if parts broken ( not consumption parts, we will take place a new one as soon as possible.
Q5: I don't know which kind of Laser fiber laser cutting machine is suit for me
A5: Just tell us your working industry
What kind of metal you need to cut and how thickness
What metal size you need to cut, then we will recommend you best suit fiber laser cutter
Look forward to hearing from you
